383 max wedge heads ??

[Hemivision]

Hi there..l recently picked up a 69 ish year 383...the casting numbers in the heads seem to read they are off of a 1964 426 max max wedge...does that make any sense...l found that strange..any thoughts..??



[John Rimel]

Hi there..l recently picked up a 69 ish year 383...the casting numbers in the heads seem to read they are off of a 1964 426 max max wedge...does that make any sense...l found that strange..any thoughts..??

what are the numbers?



[DetMatt1]

I’d be willing to bet that they may look like 518s but are probably 516s.



[Hemivision]

I’d be willing to bet that they may look like 518s but are probably 516s.

I thought the same so l went and took a real hard look...l may have pop em off...that Being said...would they even work..??.. Look



[DetMatt1]

I know the intake ports are huge/tall so without the rest of the appropriate max wedge parts they’re useless but valuable to the right person.



[John Rimel]

I thought the same so l went and took a real hard look...l may have pop em off...that Being said...would they even work..??.. Look

what are the numbers?



[John Rimel]

B/RB Big-Block Mopar Cylinder Head Casting Numbers

1406740 – 1958-1959, 361 B/RB-series big-block, 1.94/1.60 valves, HD, Truck

1737622 – 1958-1960, 350/361/383 B/RB-series big-block, 1.94/1.60 valves, 73.5cc

1737635 – 1958, 350/36, B/RB-series big-block, 1.94/1.60 valves, 73.5cc

1737637 – 1958-1959, 361 B/RB-series big-block, 1.94/1.60 valves

1844705 – 1958-1959, 350/361/383, B/RB-series big-block, 1.94/1.60 valves, 73.5cc

1851524 – 1958-1971, 350-413 B/RB-series big-block, Truck

2202594 – 1958-1971, 350-413 B/RB-series big-block, Truck

1944705 – 1958-1959, 361 B/RB-series big-block, 1.94/1.60 valves

1851509 – 1959, 361/383/413 B/RB-series big-block, 2.08/1.60 valves, HP

1737637 – 1960, 383 B/RB-series big-block, 1.94/1.60 valves

2264547 – 1960-1971, 361/413 B/RB-series big-block, Truck

2128521 – 1960-1961, 361/383/413 B/RB-series big-block, 2.08/1.60 valves, 73.5cc, 300F

2128522 – 1960-1961, 361/383, B/RB-series big-block, 1.94/1.60 valves, 73.5cc

2899913 – 1960-1971, 413 B/RB-series big-block, Truck

2206324 – 1961-1962, 361/383/413 B/RB-series big-block, 2.08/1.60 valves

2206924 – 1961-1962, 361/383/413 B/RB-series big-block, 2.08/1.60 valves, 73.5cc, 300H

2402286 – 1962, 413 B/RB-series big-block, 2.08/1.88 valves, Max Wedge, 81cc

2402557 – 1963, 413 B/RB-series big-block, 2.08/1.74 valves, 73.5cc, 300J/early K

2406209 – 1963, 413 B/RB-series big-block, 2.08/1.88 valves, Max Wedge, 81cc

2406740 – 1963-1968, 361, 413 B/RB-series big-block, Truck and Marine

2463209 – 1963, 426 B/RB-series big-block, 2.08/1.88 valves, Max Wedge

2463200 – 1963, 361/383/413 B/RB-series big-block, 2.08/1.60 valves, 73.5cc

2406516 – 1964-1967, 361/383 B/RB-series big-block, 2.08/1.60 valves, 73.5cc, 300L

2406518 – 1964, 426 B/RB-series big-block, 2.08/1.88 valves, Max Wedge, 86cc

2408520 – 1964, 413 B/RB-series big-block, 2.08/1.60 valves, 73.5cc, 300K w/ Ram intake

2268341 – 1965, 426 B/RB-series big-block

2406780 – 1965-67 383 B/RB-series big-block, Truck

2406158 – 1967, 440 B/RB-series big-block, 2.08/1.60 valves, 73.5cc

2708915 – 1967 440 B/RB-series big-block, 2.08/1.74 valves, 73.5cc, HP

2780915 – 1967, 440 B/RB-series big-block, 2.08/1.74 valves, HP

2843906 – 1968-1970, 383/440 B/RB-series big-block, 2.08/1.74 valves

2951250 – 1968, 440 B/RB-series big-block, 2.08/1.74 valves, 79.5cc

3462346 – 1971-1972, 383/400/440 B/RB-series big-block, 2.08/1.74 valves, 79.5cc

2466676 – 1971-1977, 361/413 B/RB-series big-block, Truck and Marine

2899943 – 1971-1977, 361/413 B/RB-series big-block, Truck

3462345 – 1972-1973, 400/440, B/RB-series big-block, 2.08/1.74 valves, Emissions

3462346 – 1973, 400/440 B/RB-series big-block, 2.08/1.74 valves. 81.5cc

3751213 – 1973, 400/440 B/RB-series big-block, 2.08/1.74 valves, Motor Home

3769902 – 1974, 400/440 B/RB-series big-block, 2.08/1.74 valves

3769975 – 1975, 400/440 B/RB-series big-block, 2.08/1.74 valves, 83.1cc

4006452 – 1976-1978, 400/440 B/RB-series big-block, 2.08/1.74 valves, 81.5cc

4021051 – 1977-1986, 360 B/RB-series big-block, 1.88/1.60 valves

2806887 – 426 B/RB-series big-block, Marine and Industrial

3614476 – MOPAR Stage IV, B/RB-series big-block, 2.08/1.74 valves

4286526 – MOPAR Stage V, B/RB-series big-block, 2.08/1.74 valves



[Hemivision]

B/RB Big-Block Mopar Cylinder Head Casting Numbers

1406740 – 1958-1959, 361 B/RB-series big-block, 1.94/1.60 valves, HD, Truck

1737622 – 1958-1960, 350/361/383 B/RB-series big-block, 1.94/1.60 valves, 73.5cc

1737635 – 1958, 350/36, B/RB-series big-block, 1.94/1.60 valves, 73.5cc

1737637 – 1958-1959, 361 B/RB-series big-block, 1.94/1.60 valves

1844705 – 1958-1959, 350/361/383, B/RB-series big-block, 1.94/1.60 valves, 73.5cc

1851524 – 1958-1971, 350-413 B/RB-series big-block, Truck

2202594 – 1958-1971, 350-413 B/RB-series big-block, Truck

1944705 – 1958-1959, 361 B/RB-series big-block, 1.94/1.60 valves

1851509 – 1959, 361/383/413 B/RB-series big-block, 2.08/1.60 valves, HP

1737637 – 1960, 383 B/RB-series big-block, 1.94/1.60 valves

2264547 – 1960-1971, 361/413 B/RB-series big-block, Truck

2128521 – 1960-1961, 361/383/413 B/RB-series big-block, 2.08/1.60 valves, 73.5cc, 300F

2128522 – 1960-1961, 361/383, B/RB-series big-block, 1.94/1.60 valves, 73.5cc

2899913 – 1960-1971, 413 B/RB-series big-block, Truck

2206324 – 1961-1962, 361/383/413 B/RB-series big-block, 2.08/1.60 valves

2206924 – 1961-1962, 361/383/413 B/RB-series big-block, 2.08/1.60 valves, 73.5cc, 300H

2402286 – 1962, 413 B/RB-series big-block, 2.08/1.88 valves, Max Wedge, 81cc

2402557 – 1963, 413 B/RB-series big-block, 2.08/1.74 valves, 73.5cc, 300J/early K

2406209 – 1963, 413 B/RB-series big-block, 2.08/1.88 valves, Max Wedge, 81cc

2406740 – 1963-1968, 361, 413 B/RB-series big-block, Truck and Marine

2463209 – 1963, 426 B/RB-series big-block, 2.08/1.88 valves, Max Wedge

2463200 – 1963, 361/383/413 B/RB-series big-block, 2.08/1.60 valves, 73.5cc

2406516 – 1964-1967, 361/383 B/RB-series big-block, 2.08/1.60 valves, 73.5cc, 300L

2406518 – 1964, 426 B/RB-series big-block, 2.08/1.88 valves, Max Wedge, 86cc

2408520 – 1964, 413 B/RB-series big-block, 2.08/1.60 valves, 73.5cc, 300K w/ Ram intake

2268341 – 1965, 426 B/RB-series big-block

2406780 – 1965-67 383 B/RB-series big-block, Truck

2406158 – 1967, 440 B/RB-series big-block, 2.08/1.60 valves, 73.5cc

2708915 – 1967 440 B/RB-series big-block, 2.08/1.74 valves, 73.5cc, HP

2780915 – 1967, 440 B/RB-series big-block, 2.08/1.74 valves, HP

2843906 – 1968-1970, 383/440 B/RB-series big-block, 2.08/1.74 valves

2951250 – 1968, 440 B/RB-series big-block, 2.08/1.74 valves, 79.5cc

3462346 – 1971-1972, 383/400/440 B/RB-series big-block, 2.08/1.74 valves, 79.5cc

2466676 – 1971-1977, 361/413 B/RB-series big-block, Truck and Marine

2899943 – 1971-1977, 361/413 B/RB-series big-block, Truck

3462345 – 1972-1973, 400/440, B/RB-series big-block, 2.08/1.74 valves, Emissions

3462346 – 1973, 400/440 B/RB-series big-block, 2.08/1.74 valves. 81.5cc

3751213 – 1973, 400/440 B/RB-series big-block, 2.08/1.74 valves, Motor Home

3769902 – 1974, 400/440 B/RB-series big-block, 2.08/1.74 valves

3769975 – 1975, 400/440 B/RB-series big-block, 2.08/1.74 valves, 83.1cc

4006452 – 1976-1978, 400/440 B/RB-series big-block, 2.08/1.74 valves, 81.5cc

4021051 – 1977-1986, 360 B/RB-series big-block, 1.88/1.60 valves

2806887 – 426 B/RB-series big-block, Marine and Industrial

3614476 – MOPAR Stage IV, B/RB-series big-block, 2.08/1.74 valves

4286526 – MOPAR Stage V, B/RB-series big-block, 2.08/1.74 valves



[Hemivision]

what are the numbers?

2406518...l am at work right now l bet you are right..the 8 is a 6 not the first time that's happened..and the ports don't look huge to me...l may just pop a head off to get a perfect look at the numbers...



[DetMatt1]

They also don’t have the exhaust crossover port on the intake side. You shouldn’t need to completely remove them to determine what you have. I mean look at those intake ports.



[Hemivision]

I will check when l get home but l think they have the crossover port...that would end that...thanks...l will let you guys know..thanks for your help..
