oil pan 383 71 cuda

[gbrx5]

Putting on rear sump oil pan on 1971 383 engine any issues or concerns or things I should not buy in regards to clearance issues on a 1971 Cuda



[moparleo]

Car came with center sump.



[challenger6pak]

Rear sump will sit on the K-frame. Ebodies are not rear sump. 60's though 80's big block truck and van are rear sump. Take some measurments.



[DetMatt1]

Wait a minute, rear sump would clear the k frame but the center link of the steering would be an issue. Either way you have to stick with a center sump.



[challenger6pak]

You are right. When you spend the day working on a Firebird, it messes with your head.



[DetMatt1]

Should we start calling you Ponch??



[challenger6pak]

LOL. It pays the bills.



[moparlee]

I know that a 6 qt '70 or '71 hemi pan will fit. For some reason my original '71 383 Challenger came from the factory with a 6 qt hemi pan on it and it has no clearance issues. 7 qts with the filter which is 2 qts more than the stock pan, I like it.



[gbrx5]

So a Deeper Center sump should be no issue



[challenger6pak]

You may want to run a skid plate on your K frame



[71Plym]

You may want to consider a low profile pan, like a Milodon, which has side kick outs for increased capacity (7 qt) while still having decent ground clearance.
