Suspension question

[Challenger RTA]

Now for the rest of the story. ////
/// F70/14 Rim Width6 - 7” Section Width 8.75” Overall Diameter26.45” Rolling Circumference 83.10”

Rev./ Mile 762 Tread Width 6.55” /// 205/60R15
91H SL Tire Weight 22 lbs. Rim Width Range 5.5-7.5" Meas. Rim Width 6" Sect. Width 8.2 Tread Width na Overall Diam.24.7" Revs. Per Mile 842
/// P205/70R15
95T SL
680 A B 1,499 lbs. 44 psi 11.5/32" 22 lbs. 5-7" 6" 8.2" 6.7" 26.3" 790 /// P225/50ZR15
90W SL
40 B A 1,301 lbs. 51 psi 4/32" 20 lbs. 6-8" 7" 9.1" 8.7" 23.6" 881 /// 225/50ZR17
94W SL
340 AA A 1,477 lbs. 51 psi 9.5/32" 26 lbs. 6-8" 7" 9.2" 9" 25.9" 803 /// 225/55ZR17
97W SL
340 AA A 1,609 lbs. 51 psi 9.5/32" 27 lbs. 6-8" 7" 9.2" 8.7" 26.8" 777 /// P255/60R15
102S SL
400 A B 1,885 lbs. 35 psi 11/32" 32 lbs. 7-9" 7.5" 10.2" 9.1" 27.1" 769 /// P225/60R15
95S SL
400 A B 1,521 lbs. 35 psi 11/32" 24 lbs. 6-8" 6.5" 9" 7" 25.6" 813



[moparleo]

And for the real rest of the story published tire specs are approximate.
Tire sizing is not standard in the industry. Only load capacity is regulated by the D.O.T. .
Take 4 different tire manufacturers and stand the same sizing of tires side by side and they will be + or - up to 3%.
This is one of the reasons that tires should always be matched in pairs on the same especially on modern cars with ABS brakes.



[bc3j]

@bc3j Did you choose 15/16" instead of 1-1/8" to get the look you wanted or to get within the typical 24-25" fender height?
I am preparing to lower my front suspension. Fender lip is at 27" and definitely too high. Tire/wheel combo is Goodyear Polyglas GT F60x15 on 15x7 steelies.

That was the look I wanted. For curiosity I measured from factory locations. I’m running 235/60-15 all around. No problem rubbing or hitting anywhere. My wheels are also 15x7. I set fender height first for the look then measured factory locations just to see what it was. It didn’t matter to me what the actual number was, just got the look I wanted and had it aligned. It just turned out to be 15/16”.



[MoparCarGuy]

@bc3j Thanks for response. I will do the same (pick what I like for height within reason) and then head to the alignment rack.
